Zhuoxing CNC Oscillating Knife Cutting Clothing Machine Curtain Fabrics Cutting Table

Jinan Zhuoxing Intelligent Technology Co., Ltd.
  • After-sales Service：Video Call Training
  • Waterproof Rating：IPX-3
  • Warranty：3-year
  • Certification：CE, ISO 9001:2000, ISO 9001:2008
  • Condition：New
  • Control：Automatic

Base Info

  • Model NO.：ZX-1625VA
  • Application：Paper, Plastic, Leather, Fabric
  • Power Source：Electric
  • Layout：Horizontal
  • Item：Automated Clothing Cutting Machine for Knitwear
  • Working Area：1600*2500mm
  • Rated Power：11kw
  • Max. Cutting Speed：1200mm,S
  • Cutting Thickness：0.1-20mm
  • Cutting Accuracy：0.1mm
  • Materials Fixed Model：Vacuum Adsorption
  • Format Supported：Dxf, Plt, etc
  • Weight：980kg
  • Transport Package：Export Wooden Case
  • Specification：3300x2250x1250mm
  • Trademark：ZHUOXING
  • Origin：Jinan, Shandong, China
  • HS Code：8479899990
  • Production Capacity：100 Sets,Month

Description

Basic Info.

Model NO. ZX-1625VA Application Paper, Plastic, Leather, Fabric Power Source Electric Layout Horizontal Item Automated Clothing Cutting Machine for Knitwear Working Area 1600*2500mm Rated Power 11kw Max. Cutting Speed 1200mm/S Cutting Thickness 0.1-20mm Cutting Accuracy 0.1mm Materials Fixed Model Vacuum Adsorption Format Supported Dxf, Plt, etc Weight 980kg Transport Package Export Wooden Case Specification 3300x2250x1250mm Trademark ZHUOXING Origin Jinan, Shandong, China HS Code 8479899990 Production Capacity 100 Sets/Month

Product Description

Zhuoxing CNC Oscillating Knife Cutting Clothing Machine Curtain Fabrics Cutting Table


Zhuoxing CNC Oscillating Knife Cutting Clothing Machine Curtain Fabrics Cutting Table

Zhuoxing CNC Oscillating Knife Cutting Clothing Machine Curtain Fabrics Cutting Table

ModelZX-1625VA
Working Area(W*L) 1600*2500mm
Rated Power11kw
Max. Cutting Speed1200mm/s
No-load Speed1500mm/s
Cutting Thickness0.1-20mm (depending on the materials)
Cutting Accuracy±0.1mm
Transmission InterfaceEthernet
Drive SystemServo motor, linear guide rail, rack, and pinion
Material Fixed ModeVacuum adsorption
Format SupportedDXF, PLT, etc
Operation PropertyOnline/offline operation, continuous cutting with high efficiency, 7*24 hours with zero downtime
Safety DeviceAn infrared sensing device, 4 emergency stop buttons, intelligent anti-collision device
Power SupplyAC 110V/220V/380V, 50/60Hz, single/three-phase
Dimension3300x2250x1250mm
Weight980kg
